• New Modern Styling and Color with Wood Endbells
• EXCLUSIVE BI-MODULAR CONCEPT
• All LED Illumination !
• Start with as few modules as needed - expand later !
• Machine control for all inputs
• All DC Control - Replace Modules while on air witout pops or clicks
• Electronic switching
• No audio transformers
• Penny and Giles linear conductive plastic pots
• Selector switches
• Engraved front panel
• Pluggable miniature terminal strips
• Up to eight patchable microphone preamplifiers
• Easy input level selection
• Self-resetting "Poly Fuses" protect individual circuit boards
• Standard Autolock
• Four Lighted Meters
• Built In Cue Speaker

Sources:
Up to 60 stereo inputs
4 or 8 Microphones

Impedances:
Microphone, 150 ohm
High level, 20k ohm bridge or 600 ohm terminate
External monitor, 20k or 600 ohm

Levels:
Microphone, -65 to -50 dBm
High level, -10 to +10 dBm
External monitor, -10 to +10 dBm

SNR:
Programs/Monitor, better than -90 dB at +18 dBm out
Headphone/Cue, better than -80 dB at 2 watts

Power Source:
Universal 85-264 VAC 47- 440Hz

Mounting & Dimensions:
Table top with bottom or back cable entry
Height: 8.8" (22.35 cm)
Depth: 28.75" (73.1 cm)
Width: 45.4" (115.32 cm)
